RELIABILITY: Constructed from high-grade galvanized steel to ensure maximum corrosion resistance and durability in harsh saltwater environments.

Key Features

• ✔ Self-launching & self-righting design
• ✔ High holding power in sand and mud
• ✔ Hot-dipped galvanized finish
• ✔ Ideal for use with bow rollers

Technical Specs

Weight:	6 kg (13.2 lbs)
Overall Length:	~595 mm
Max Width:	~265 mm
Shank Thickness:	10 mm
Chain Size:	6 - 7 mm

Vessel Type	Recommended Length	Displacement Notes
Small Yachts / Dayboats	Up to 9.5m (31ft)	Standard conditions
Motorboats / Tenders	6m - 9m (20ft - 30ft)	General purpose anchoring

Is this a genuine original part?

This is a premium quality aftermarket replacement anchor, manufactured to meet or exceed the performance specifications of the original Delta design.

How do I know if it is compatible with my windlass?

This 6kg anchor is a standard Delta-style profile. It is designed to fit most standard 6kg bow rollers and is compatible with Lewmar windlass systems using 6mm or 7mm chain.

Will this anchor hold in rocky seabeds?

The Delta design is specialized for sand, mud, and grass. While it can hook on rocks, plough-style anchors are most effective in penetrable substrates.
